MODULE FOR FLUE GAS TREATMENT

MODULE'S TECHNICAL PARAMETERS
Module is a ready-to-install system
Module is a ready-to-install system of a container type, which consists of the following components:

  • Electron accelerator;
  • Radiation shield body;
  • In-built pipeline system for supplying flue gas under electron beam;
  • Cooling system;
  • Ozone exhaust system;
  • Fire safety system;
  • Radiation monitoring and control system;
  • Control system;
And other supporting systems.
Power consumption
Electric power consumption: 100 to 450 kW/hour, depending on the power rating of electron accelerator and module's required capacity.
Placement
The module may be placed directly at industrial facilities and can be integrated with existing systems without halting the process.
Compact size
Maximum dimensions:
8m x 6.5m x 6m (concrete shield).
    Safety
    • Module is equipped with radiation dose sensors.
    • Metal or concrete body ensure complete safety of employees from radiation.
    Capacity
    Module's capacity depends on the flue gas treatment requirements.
    Module is equipped with:

    Electron accelerator: energy 5 MeV, power from 50 kW to 100 kW, operates in E-beam mode.

    Radiation shield: Depending on the premises area and technical requirements of the customer, different materials may be used for radiation shield: concrete or metal.

    Ozone exhaust system: depends on the module's capacity.

    Emergency shutdown system: in case of any accidental event the electron accelerator will be switched off automatically.

    In-built pipeline system: supplies flue gas into the ionizing irradiation area.

    Fire safety system: triggered in emergency situations. Electron accelerator will be switched off and fire extinguishing system will be turned on, in automatic or manual mode.

    Control system: dosimetry, conveyor speed control, electron accelerator control, fire extinguishing, cooling, ventilation and emergency shutdown of the accelerator.

    --------------------------------------------
    Usage of compact size modules allows to reduce costs for construction of buildings for irradiation treatment of goods and materials
    ---------------------------------------------
    Usage of modules allows to save time on construction and commissioning of facilities for irradiation treatment of goods and materials
    ---------------------------------------------
    Placing of modules directly at industrial facilities allows to use the module as an additional treatment step in an existing treatment system to ensure complete elimination of pathogens and contaminants.
    --------------------------------------------
    Placing modules directly at industrial facilities allows to avoid additional expenses for transportation of products and materials to treatment facilities
    --------------------------------------------
    Module operates by using only electrical power
    --------------------------------------------
    Integration with existing treatment systems and production processes without its interruption
